GPC Light Duty Bolt Hole Castors (LDBHC)

GPC light-duty bolt hole castors provide smooth movement for trucks and trolleys. Available in wheel sizes from 50mm to 200mm with load capacities up to 100kg.
GPC Light Duty Bolt Hole Castors + LDBHC + Delivery in 3-5 Working Days
GPC Industries: GPC Light Duty Bolt Hole Castors
From £14.77 (inc. VAT)£12.31 (ex. VAT)
SKUImageProduct1+

Prices include VAT

Prices exclude VAT

Quantity
S27GPC Light Duty Bolt Hole Castors: size/model: Square - 27 - 30mmGPC Light Duty Bolt Hole Castors: size/model: Square - 27 - 30mm £14.77 £12.31
S24GPC Light Duty Bolt Hole Castors: size/model: Square - 24 - 27mmGPC Light Duty Bolt Hole Castors: size/model: Square - 24 - 27mm £14.77 £12.31
S21GPC Light Duty Bolt Hole Castors: size/model: Square - 21.5 - 24mmGPC Light Duty Bolt Hole Castors: size/model: Square - 21.5 - 24mm £14.77 £12.31
R27GPC Light Duty Bolt Hole Castors: size/model: Round - 27 - 30mmGPC Light Duty Bolt Hole Castors: size/model: Round - 27 - 30mm £14.77 £12.31
R24GPC Light Duty Bolt Hole Castors: size/model: Round - 24 - 27mmGPC Light Duty Bolt Hole Castors: size/model: Round - 24 - 27mm £14.77 £12.31
R21GPC Light Duty Bolt Hole Castors: size/model: Round - 21.5 - 24mmGPC Light Duty Bolt Hole Castors: size/model: Round - 21.5 - 24mm £14.77 £12.31
R19GPC Light Duty Bolt Hole Castors: size/model: Round - 19 - 21.5mmGPC Light Duty Bolt Hole Castors: size/model: Round - 19 - 21.5mm £14.77 £12.31
50DRLBH10PPGPC Light Duty Bolt Hole Castors: size/model: 50mm - White Polypropylene - Swivel £16.84 £14.03
S36GPC Light Duty Bolt Hole Castors: size/model: Square - 36 - 40mmGPC Light Duty Bolt Hole Castors: size/model: Square - 36 - 40mm £17.29 £14.41
S31GPC Light Duty Bolt Hole Castors: size/model: Square - 31 - 35mmGPC Light Duty Bolt Hole Castors: size/model: Square - 31 - 35mm £17.29 £14.41
R31GPC Light Duty Bolt Hole Castors: size/model: Round - 31 - 35mmGPC Light Duty Bolt Hole Castors: size/model: Round - 31 - 35mm £17.30 £14.42
50DRLBH10GRGGPC Light Duty Bolt Hole Castors: size/model: 50mm - Grey Rubber Tyred - SwivelGPC Light Duty Bolt Hole Castors: size/model: 50mm - Grey Rubber Tyred - Swivel £17.35 £14.46
50DRLBH10PPSWBGPC Light Duty Bolt Hole Castors: size/model: 50mm - White Polypropylene - BrakedGPC Light Duty Bolt Hole Castors: size/model: 50mm - White Polypropylene - Braked £17.88 £14.90
50DRLBH10GRGSWBGPC Light Duty Bolt Hole Castors: size/model: 50mm - Grey Rubber Tyred - BrakedGPC Light Duty Bolt Hole Castors: size/model: 50mm - Grey Rubber Tyred - Braked £18.41 £15.34
75DRLBH10GRGGPC Light Duty Bolt Hole Castors: size/model: 75mm - Grey Rubber Tyred - SwivelGPC Light Duty Bolt Hole Castors: size/model: 75mm - Grey Rubber Tyred - Swivel £18.88 £15.73
75DRLBH10PPGPC Light Duty Bolt Hole Castors: size/model: 75mm - White Polypropylene - Swivel £18.88 £15.73
75DRLBH10PPSWBGPC Light Duty Bolt Hole Castors: size/model: 75mm - White Polypropylene - BrakedGPC Light Duty Bolt Hole Castors: size/model: 75mm - White Polypropylene - Braked £19.25 £16.04
75DRLBH10GRGSWBGPC Light Duty Bolt Hole Castors: size/model: 75mm - Grey Rubber Tyred - BrakedGPC Light Duty Bolt Hole Castors: size/model: 75mm - Grey Rubber Tyred - Braked £19.93 £16.61
100DRLBH12PPGPC Light Duty Bolt Hole Castors: size/model: 100mm - White Polypropylene - Swivel £20.56 £17.13
100DRLBH10GRGGPC Light Duty Bolt Hole Castors: size/model: 100mm - Grey Rubber Tyred - SwivelGPC Light Duty Bolt Hole Castors: size/model: 100mm - Grey Rubber Tyred - Swivel £21.46 £17.88
100DRLBH10GRGSWBGPC Light Duty Bolt Hole Castors: size/model: 100mm - Grey Rubber Tyred - BrakedGPC Light Duty Bolt Hole Castors: size/model: 100mm - Grey Rubber Tyred - Braked £22.24 £18.53
100DRLBH12PPSWBGPC Light Duty Bolt Hole Castors: size/model: 100mm - White Polypropylene - BrakedGPC Light Duty Bolt Hole Castors: size/model: 100mm - White Polypropylene - Braked £22.76 £18.97
125DRLBH12PPGPC Light Duty Bolt Hole Castors: size/model: 125mm - White Polypropylene - Swivel £22.97 £19.14
125DRLBH12GRGGPC Light Duty Bolt Hole Castors: size/model: 125mm - Grey Rubber Tyred - SwivelGPC Light Duty Bolt Hole Castors: size/model: 125mm - Grey Rubber Tyred - Swivel £23.98 £19.98
125DRLBH12PPSWBGPC Light Duty Bolt Hole Castors: size/model: 125mm - White Polypropylene - BrakedGPC Light Duty Bolt Hole Castors: size/model: 125mm - White Polypropylene - Braked £24.07 £20.06
125DRLBH12GRGSWBGPC Light Duty Bolt Hole Castors: size/model: 125mm - Grey Rubber Tyred - BrakedGPC Light Duty Bolt Hole Castors: size/model: 125mm - Grey Rubber Tyred - Braked £26.70 £22.25
S27
GPC Light Duty Bolt Hole Castors size/model: Square - 27 - 30mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Square - 27 - 30mm
S24
GPC Light Duty Bolt Hole Castors size/model: Square - 24 - 27mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Square - 24 - 27mm
S21
GPC Light Duty Bolt Hole Castors size/model: Square - 21.5 - 24mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Square - 21.5 - 24mm
R27
GPC Light Duty Bolt Hole Castors size/model: Round - 27 - 30mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Round - 27 - 30mm
R24
GPC Light Duty Bolt Hole Castors size/model: Round - 24 - 27mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Round - 24 - 27mm
R21
GPC Light Duty Bolt Hole Castors size/model: Round - 21.5 - 24mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Round - 21.5 - 24mm
R19
GPC Light Duty Bolt Hole Castors size/model: Round - 19 - 21.5mm
1+ : £14.77
GPC Light Duty Bolt Hole Castors: size/model: Round - 19 - 21.5mm
50DRLBH10PP
GPC Light Duty Bolt Hole Castors size/model: 50mm - White Polypropylene - Swivel
1+ : £16.84
S36
GPC Light Duty Bolt Hole Castors size/model: Square - 36 - 40mm
1+ : £17.29
GPC Light Duty Bolt Hole Castors: size/model: Square - 36 - 40mm
S31
GPC Light Duty Bolt Hole Castors size/model: Square - 31 - 35mm
1+ : £17.29
GPC Light Duty Bolt Hole Castors: size/model: Square - 31 - 35mm
R31
GPC Light Duty Bolt Hole Castors size/model: Round - 31 - 35mm
1+ : £17.30
GPC Light Duty Bolt Hole Castors: size/model: Round - 31 - 35mm
50DRLBH10GRG
GPC Light Duty Bolt Hole Castors size/model: 50mm - Grey Rubber Tyred - Swivel
1+ : £17.35
GPC Light Duty Bolt Hole Castors: size/model: 50mm - Grey Rubber Tyred - Swivel
50DRLBH10PPSWB
GPC Light Duty Bolt Hole Castors size/model: 50mm - White Polypropylene - Braked
1+ : £17.88
GPC Light Duty Bolt Hole Castors: size/model: 50mm - White Polypropylene - Braked
50DRLBH10GRGSWB
GPC Light Duty Bolt Hole Castors size/model: 50mm - Grey Rubber Tyred - Braked
1+ : £18.41
GPC Light Duty Bolt Hole Castors: size/model: 50mm - Grey Rubber Tyred - Braked
75DRLBH10GRG
GPC Light Duty Bolt Hole Castors size/model: 75mm - Grey Rubber Tyred - Swivel
1+ : £18.88
GPC Light Duty Bolt Hole Castors: size/model: 75mm - Grey Rubber Tyred - Swivel
75DRLBH10PP
GPC Light Duty Bolt Hole Castors size/model: 75mm - White Polypropylene - Swivel
1+ : £18.88
75DRLBH10PPSWB
GPC Light Duty Bolt Hole Castors size/model: 75mm - White Polypropylene - Braked
1+ : £19.25
GPC Light Duty Bolt Hole Castors: size/model: 75mm - White Polypropylene - Braked
75DRLBH10GRGSWB
GPC Light Duty Bolt Hole Castors size/model: 75mm - Grey Rubber Tyred - Braked
1+ : £19.93
GPC Light Duty Bolt Hole Castors: size/model: 75mm - Grey Rubber Tyred - Braked
100DRLBH12PP
GPC Light Duty Bolt Hole Castors size/model: 100mm - White Polypropylene - Swivel
1+ : £20.56
100DRLBH10GRG
GPC Light Duty Bolt Hole Castors size/model: 100mm - Grey Rubber Tyred - Swivel
1+ : £21.46
GPC Light Duty Bolt Hole Castors: size/model: 100mm - Grey Rubber Tyred - Swivel
100DRLBH10GRGSWB
GPC Light Duty Bolt Hole Castors size/model: 100mm - Grey Rubber Tyred - Braked
1+ : £22.24
GPC Light Duty Bolt Hole Castors: size/model: 100mm - Grey Rubber Tyred - Braked
100DRLBH12PPSWB
GPC Light Duty Bolt Hole Castors size/model: 100mm - White Polypropylene - Braked
1+ : £22.76
GPC Light Duty Bolt Hole Castors: size/model: 100mm - White Polypropylene - Braked
125DRLBH12PP
GPC Light Duty Bolt Hole Castors size/model: 125mm - White Polypropylene - Swivel
1+ : £22.97
125DRLBH12GRG
GPC Light Duty Bolt Hole Castors size/model: 125mm - Grey Rubber Tyred - Swivel
1+ : £23.98
GPC Light Duty Bolt Hole Castors: size/model: 125mm - Grey Rubber Tyred - Swivel
125DRLBH12PPSWB
GPC Light Duty Bolt Hole Castors size/model: 125mm - White Polypropylene - Braked
1+ : £24.07
GPC Light Duty Bolt Hole Castors: size/model: 125mm - White Polypropylene - Braked
125DRLBH12GRGSWB
GPC Light Duty Bolt Hole Castors size/model: 125mm - Grey Rubber Tyred - Braked
1+ : £26.70
GPC Light Duty Bolt Hole Castors: size/model: 125mm - Grey Rubber Tyred - Braked
GPC Light Duty Bolt Hole Castors + LDBHC + Delivery in 3-5 Working Days
GPC Light Duty Bolt Hole Castors - Smooth and Reliable Mobility


Our GPC Light Duty Bolt Hole Castors (LDBHC) are an affordable and durable solution for trucks, trolleys, and material handling equipment. Designed to provide smooth movement and excellent manoeuvrability, these castors come in wheel sizes ranging from 50mm to 200mm, making them suitable for a variety of applications. Available in swivel and braked versions, they offer flexibility and ease of use in industrial, commercial, and everyday environments.

  • Wheel sizes: 50mm, 75mm, 100mm, 125mm
  • Wheel types: White polypropylene, grey rubber
  • Load capacity: 40kg to 100kg depending on size and material
  • Overall height: 71mm to 150mm
  • Bearing type: Plain bearings for smooth operation
  • Suits bolts with diameter: 10mm or 20mm depending on model

Available Sizes and Specifications:

  • 50mm White Polypropylene – Load capacity: 40kg, Overall height: 71mm, Suits bolts: 10mm
  • 50mm Grey Rubber Tyred – Load capacity: 40kg, Overall height: 71mm, Suits bolts: 10mm
  • 75mm White Polypropylene – Load capacity: 50kg, Overall height: 95mm, Suits bolts: 10mm
  • 75mm Grey Rubber Tyred – Load capacity: 50kg, Overall height: 95mm, Suits bolts: 10mm
  • 100mm White Polypropylene – Load capacity: 80kg, Overall height: 128mm, Suits bolts: 20mm
  • 100mm Grey Rubber Tyred – Load capacity: 80kg, Overall height: 128mm, Suits bolts: 20mm
  • 125mm White Polypropylene – Load capacity: 100kg, Overall height: 150mm, Suits bolts: 20mm
  • 125mm Grey Rubber Tyred – Load capacity: 100kg, Overall height: 150mm, Suits bolts: 20mm

Tube Sizes Available:

  • Round Tubes: 19mm - 21.5mm (R19), 21.5mm - 24mm (R21), 24mm - 27mm (R24), 27mm - 30mm (R27), 31mm - 35mm (R31)
  • Square Tubes: 21.5mm - 24mm (S21), 24mm - 27mm (S24), 27mm - 30mm (S27), 31mm - 35mm (S31), 36mm - 40mm (S36)


These versatile bolt hole castors are built for light-duty applications, ensuring easy movement and long-lasting performance. Whether you need to upgrade your trolleys, trucks, or storage units, these castors provide a reliable and cost-effective solution.
