GPC Medium Duty Bolt Hole Castors (BHMDC)
| SKU | Product | 1+ Prices include VAT Prices exclude VAT | Quantity | |
|---|---|---|---|---|
| 100DRBH12PSB | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Black Rubber Tyred - Swivel | £29.59 £24.66 | ||
| 125DRBH12PSB | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Black Rubber Tyred - Swivel | £30.59 £25.49 | ||
| 100DRBH12NY | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Nylon - Swivel | £30.85 £25.71 | ||
| 125DRBH12NY | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Nylon - Swivel | £31.21 £26.01 | ||
| 100DRBH12BNB | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Blue Rubber Tyred - Swivel | £33.16 £27.63 | ||
| 125DRBH12BNB | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Blue Rubber Tyred - Swivel | £33.95 £28.29 | ||
| 100DRBH12PNBJ | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Polyurethane - Swivel | £35.15 £29.29 | ||
| 100DRBH12PSBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Black Rubber Tyred - Braked | £36.05 £30.04 | ||
| 125DRBH12PNBJ | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Polyurethane - Swivel | £36.52 £30.43 | ||
| 100DRBH12NYSWB | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Nylon - Braked | £37.00 £30.83 | ||
| 125DRBH12PSBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Black Rubber Tyred - Braked | £37.31 £31.09 | ||
| 125DRBH12NYSWB | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Nylon - Braked | £37.67 £31.39 | ||
| 160DRBH12PSB | GPC Medium Duty Bolt Hole Castors: size/model: 160mm - Black Rubber Tyred - Swivel | £38.15 £31.79 | ||
| 200DRBH12PSB | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Black Rubber Tyred - Swivel | £39.61 £33.01 | ||
| 100DRBH12BNBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Blue Rubber Tyred - Braked | £39.88 £33.23 | ||
| 125DRBH12BNBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Blue Rubber Tyred - Braked | £40.25 £33.54 | ||
| 100DRBH12PNBJSWB | GPC Medium Duty Bolt Hole Castors: size/model: 100mm - Polyurethane - Braked | £41.62 £34.68 | ||
| 125DRBH12PNBJSWB | GPC Medium Duty Bolt Hole Castors: size/model: 125mm - Polyurethane - Braked | £42.92 £35.77 | ||
| 150DRBH12NY | GPC Medium Duty Bolt Hole Castors: size/model: 150mm - Nylon - Swivel | £44.65 £37.21 | ||
| 160DRBH12PSBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 160mm - Black Rubber Tyred - Braked | £45.23 £37.69 | ||
| 160DRBH12BNB | GPC Medium Duty Bolt Hole Castors: size/model: 160mm - Blue Rubber Tyred - Swivel | £45.97 £38.31 | ||
| 200DRBH12PSBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Black Rubber Tyred - Braked | £46.75 £38.96 | ||
| 200DRBH12NY | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Nylon - Swivel | £48.49 £40.41 | ||
| 150DRBH12PNBJ | GPC Medium Duty Bolt Hole Castors: size/model: 150mm - Polyurethane - Swivel | £48.76 £40.63 | ||
| 150DRBH12NYSWB | GPC Medium Duty Bolt Hole Castors: size/model: 150mm - Nylon - Braked | £51.37 £42.81 | ||
| 160DRBH12BNBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 160mm - Blue Rubber Tyred - Braked | £52.01 £43.34 | ||
| 200DRBH12BNB | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Blue Rubber Tyred - Swivel | £52.63 £43.86 | ||
| 200DRBH12NYSWB | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Nylon - Braked | £54.53 £45.44 | ||
| 150DRBH12PNBJSWB | GPC Medium Duty Bolt Hole Castors: size/model: 150mm - Polyurethane - Braked | £54.58 £45.48 | ||
| 200DRBH12PNBJ | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Polyurethane - Swivel | £54.89 £45.74 | ||
| 200DRBH12BNBSWB | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Blue Rubber Tyred - Braked | £58.73 £48.94 | ||
| 200DRBH12PNBJSWB | GPC Medium Duty Bolt Hole Castors: size/model: 200mm - Polyurethane - Braked | £61.61 £51.34 |
GPC Medium Duty Bolt Hole Castors (BHMDC) are designed for smooth and controlled movement in industrial and commercial environments. Featuring pressed steel double ball race swivel heads, these castors ensure effortless manoeuvrability and durability.
Wheel sizes are available from 100mm to 200mm, with load capacities ranging from 80kg to 350kg. The overall height of each castor varies based on the wheel diameter, ensuring compatibility with different equipment. The fitting size is M12, providing a secure bolt hole attachment.
For the 100mm diameter wheels:
- Nylon wheels have a 35mm tread width and a 200kg load capacity, with an overall height of 128mm.
- Polyurethane wheels have a 38mm tread width and a 220kg load capacity, with an overall height of 128mm.
- Blue rubber-tyred wheels have a 34mm tread width and an 180kg load capacity, with an overall height of 128mm.
- Black rubber-tyred wheels have a 32mm tread width and an 80kg load capacity, with an overall height of 128mm.
For the 125mm diameter wheels:
- Nylon wheels have a 35mm tread width and a 270kg load capacity, with an overall height of 152mm.
- Polyurethane wheels have a 38mm tread width and a 270kg load capacity, with an overall height of 152mm.
- Blue rubber-tyred wheels have a 36mm tread width and a 250kg load capacity, with an overall height of 152mm.
- Black rubber-tyred wheels have a 37mm tread width and a 100kg load capacity, with an overall height of 152mm.
For the 150mm diameter wheels:
- Nylon wheels have a 40mm tread width and a 350kg load capacity, with an overall height of 185mm.
- Polyurethane wheels have a 50mm tread width and a 350kg load capacity, with an overall height of 185mm.
For the 160mm diameter wheels:
- Blue rubber-tyred wheels have a 45mm tread width and a 350kg load capacity, with an overall height of 195mm.
- Black rubber-tyred wheels have a 40mm tread width and a 175kg load capacity, with an overall height of 195mm.
For the 200mm diameter wheels:
- Nylon wheels have a 50mm tread width and a 350kg load capacity, with an overall height of 237mm.
- Polyurethane wheels have a 50mm tread width and a 350kg load capacity, with an overall height of 237mm.
- Blue rubber-tyred wheels have a 45mm tread width and a 350kg load capacity, with an overall height of 237mm.
- Black rubber-tyred wheels have a 50mm tread width and a 205kg load capacity, with an overall height of 237mm.
Each castor is fitted with a suitable bearing type, including plain bearings, ball bearings, and roller bearings, optimised for different load and movement requirements. Braked models are also available for secure positioning when required.
These castors are ideal for trolleys, carts, and other mobile equipment used in warehouses, factories, and commercial environments. Select the appropriate wheel type and size to match your application and ensure reliable mobility and performance.
