Invicta Automatic Pallet Forks – Efficient Overhead Pallet Handling (IPF-BOS-10-20)
The Invicta Automatic Pallet Forks transform an overhead crane or HIAB into an effective pallet mover, making them ideal for areas where forklifts cannot operate, such as high-rise developments or restricted spaces. These forks feature adjustable fork widths, height adjustment, and a spring-loaded self-balancing head for smooth and safe operation. The pre-fitted safety net frame enhances stability, ensuring secure handling of your load.
Specifications:
- Model IPF-BOS-10-20:
- Weight: 170kg
- Fork Length: 1000mm
- Fork Cross Section: 100 x 35mm
- Fork Opening Range: 300-1000mm
- Load Capacity: 2000kg
- Overall Height: 1800-2500mm
- Model IPF-BOS-12-20:
- Weight: 190kg
- Fork Length: 1200mm
- Fork Cross Section: 100 x 35mm
- Fork Opening Range: 300-1000mm
- Load Capacity: 2000kg
- Overall Height: 1800-2500mm
Standard Features:
- Spring-loaded self-balancing head for automatic levelling.
- Safety net frame for enhanced load security.
- Adjustable height: Clear height 1200-1900mm.
- Adjustable fork widths to accommodate various pallet sizes.
- Convenient handholds for easy positioning.
- Painted bright orange for improved visibility and safety.
Operation Instructions:
- Position the overhead crane or HIAB directly above the crane forks.
- Attach the crane/HIAB hook to the lifting eye on the attachment.
- Slacken the thumbscrews and adjust the forks to suit the pallet width.
- Tighten the thumbscrews securely onto the rail.
- Use the handholds to manually position the forks into the pallet.
- Fully insert the forks and secure the load with the safety strap.
- Lift the pallet clear of the ground and slide the restraint net underneath.
- Attach the restraint net to the six net hoops on the frame.
- Once secured, the load is ready for safe movement.
Maintenance Guidelines:
- Inspect weekly for the following:
- Weld points.
- Wear and distortion of thumb screws.
- Damaged components.
- Lock and latches.
- Pivot points.
- Check and tighten all bolts regularly.
- Lubricate pivot bars and oil the spring.
- Inspect the restraint net for wear and replace if necessary.
- Treat general surface rusting with inhibitors, primers, and paint.
- Report and repair any damage before reuse.
- Certified for six months; re-testing is required after this period per HSE guidelines.
Health & Safety Notes:
- Operators must be trained in the attachment’s use and maintenance.
- Ensure the crane and attachment can handle the intended load.
- Always use the restraint net when lifting overhead.
- Keep clear of the attachment during operation.
- Avoid shock loading and ensure smooth handling.
- Return the attachment to the floor for inspection in case of failure during operation.
- Keep hands away from all moving parts.
For more information or to request a quote, contact us today.
